Aluminum Hydroxide Flame Retardant
Molecular Formula: Al(OH)3
H.S. CODE: 2818 3000
CAS No.:21645-51-2
EINECS No.:244-492-7
Aluminum hydroxide serves as an effective flame-retardant filler, primarily comprising Al (OH)3.
This white micro powder exhibits no secondary pollution, rendering it an environmentally benign inorganic flame retardant.
Aluminum hydroxide confers flame retardancy, smoke suppression, filling properties, antistatic characteristics, and more to products. Notably, it offers advantages such as cost-effectiveness, high performance, stability, non-volatility, non-corrosiveness to equipment, and a high decomposition temperature.
Technical Index | Aluminum Hydroxide/Alumina Trihydrate/Aluminum Trihydrate |
Type | H-WF-8 | H-WF-10 | H-WF-14 | H-WF-25MSP | H-WF-25 | H-WF-50 | H-WF-90 |
AL(OH)3 %≥ | 99.6 | 99.6 | 99.6 | 99.6 | 99.6 | 99.6 | 99.6 |
SiO2 %≤ | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 |
Fe2O3 %≤ | 0.008 | 0.008 | 0.008 | 0.008 | 0.008 | 0.008 | 0.008 |
Na2O %≤ | 0.3 | 0.3 | 0.3 | 0.25 | 0.25 | 0.25 | 0.0.25 |
Moisture %≤ | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 |
Particle Size D50(μm) | 8±2 | 10±2 | 14±2 | 21±5 | 25±5 | 50±5 | 90±15 |
Whiteness % ≥ | 98 | 98 | 98 | 98 | 96 | 96 | 95 |
Oil Absorption (ml/100g)≤ | 30 | 30 | 27 | 24 | 25 | 23 | 22 |
Technical Index | Aluminum Hydroxide/Alumina Trihydrate/Aluminum Trihydrate |
Type | H-WF-1 | H-WF-2 | H-WF-5 |
AL(OH)3 %≥ | 99.7 | 99.6 | 99.6 |
SiO2 %≤ | 0.01 | 0.01 | 0.02 |
Fe2O3 %≤ | 0.008 | 0.01 | 0.008 |
Na2O %≤ | 0.28 | 0.11 | 0.3 |
Moisture %≤ | 0.2 | 0.2 | 0.2 |
Particle Size D50(μm) | 1.0-1.6 | 1.8-2.3 | 5±1 |
Whiteness % ≥ | 99 | 99 | 99 |
Oil Absorption(ml/100g)≤ | 33-36 | 31-33 | 29-31 |
All sizes above can be made surface activated treatment for improving the dosage of ATH to reach higher flame retardant effect. |
Application:
- Solid surfaces and artificial marble using MMA and Unsaturated Polyester (UP) resins.
- Building materials, damping pastes, and damping plates.
- Rubber and plastic products such as mine conveyor belts, air duct coating cloth, hoses, rubber plates, rubber liners, PVC wires and cables, and wire and cable sheaths.
- Electronics and flame-retardant resins.
- Electrical components :LDPE cable materials, LSZH wire compounds, and LSZH cables.
- Silicone rubber and rubber insulation.
- Silastic modules and foam insulation.
- Paper-making and PVC industries.
- Pouring sealants.
- Protective shells for vehicles, phones, aircraft, and computers.
Package without pallets:
1-5um:15tons/20GP;27tons/40HQ
8-10um:27tons/20GP;
14-100um:27tons/20GP.
Package with pallets:
1um:13tons/20GP;
5-8-10um:22tons/20GP;
14-100um:24tons/20GP.
ZIBO JOYREACH NEW MATERIALS CO.,LTD is a leading Manufacture of city construction products in China.Our company is mainly specialized in materials R&D,sales and exporting.We have our own exporting department which in charge of clients from abroad.Now we have cooperated with many famous solid surface enterprises abroad,Korea,Japan,Vietnam,Egypt,South East Asia and Middle Asia have our regular users.We can make D50 size customized and design ATH according to clients samples.
